Šifra proizvoda: MAJ1095S10
Naziv: MAJ1095S10 Konektor za rad u teskim uslovima, izolovan OLI95 AL/Cu 1x25-95mm2 IP20
Product code:MAJ1095S10
EAN:4744397018724
ETIM Class:EC000897
Product series:Insulated heavy duty connectors OLI
CN8 code:85369010
Unit:pcs
Package size:3
Net weight:0.119 kg
Net length:0.087 m
Net width:0.04 m
Net depth:0.06 m
Connectable conductor cross section fine-strand without cable end sleeve:25 - 95 mm²
Connectable conductor cross section fine-strand with cable end sleeve:25 - 95 mm²
Connectable conductor cross section solid-core:Not applicable
Connectable conductor cross section multi-wired:25 - 95 mm²
Rated current In:320 A
Rated voltage:690 V
Type of electrical connection 1:Screw connection
Type of electrical connection 2:Bolt connection
Number of levels:1
Number of clamp positions per level:1
Mounting method:Other
Material insulation body:Thermoplastic
Operating temperature:- - 80 °C
Inflammability class of insulation material according to UL94:-
OLI connection terminals in an insulating sleeve are designed for connecting copper and aluminum conductors with a nominal cross-section from 6 to 300 mm2. The terminals are used to connect copper or aluminum cables with flexible busbars or cables with eyes. The individual parts are made of stainless steel (yoke), copper (bridge), steel (screw) and plastic (case). These terminals are designed for heavy duty use. The terminals allow the clamping of stranded conductors without the need for end preparation (clamping with the flat surface of the washer, not with the point surface of the screw). The degree of protection of OLI connection terminals is IP20.
Materijal žice Al/Cu
Poprečni presek min. (mm²) 25
Poprečni presek mak. (mm²) 95
Ulazna žica min. (mm²) 25
Ulazna žica mak. (mm²) 95
Broj priključaka 1
Nazivna struja (A) 320
Nazivni napon (V) 690
Radna temperatura (°C) 80
Materijal Nerđajući čelik, kalajisan bakar, poliamid PA66, polikarbonat
Način montaže DIN šina, vijak
Širina artikla (mm) 40
Dužina artikla (mm) 87
Visina (mm) 60
Težina (g) 119
Šestougaoni vijak 4
Moment zatezanja (Nm) 20 Nm
IP20
✅ Na lageru:
10 kom
📦 Jedinica mere:
kom
🔢 Minimalna količina:
1
🛡️ Garancija:
5 godina
->
